Wholesalae LED Automatic Pick And Place Machine CR ZT8VA
PRODUCT DETAIL
Feature:
1:8 sets of high-speed independent rotating mounting heads.
2:Additional marble platform makes high-speed mounting more stable and accurate.
3:Track PCB plate automatic transmission, higher efficiency, lower labor costs.
4:Equipped with 8 sets of CCD flying photograph visual correction cameras to reduce feeding errors.
Image:
Specification:
|
Product name
产品名称
|
RD-ZT8VA(Eight-Head Automatic Mounter)
RD-ZT8VA(八头全自动贴片机)
|
|
Conventional patch speed
常规贴片速度
|
30000-45000 chips/h
30000-45000 chips/h
|
|
Maximum patch area
最大贴片面积
|
600mm*500mm
600mm*500mm
|
|
Z-axis stickable stroke
Z轴可贴行程
|
±20mm
±20mm
|
|
Machine weight
机器重量
|
1550kg
1550kg
|
|
Shape size
外形尺寸
|
1550mm long*1400mm wide*1500mm high
长1550mm*宽1400mm*高1500mm
|
|
Best patch speed
最佳贴片速度
|
55000 chips/h(group by group)
55000 chips/h(群取群贴)
|
|
supply voltage
电源电压
|
AC220V 50HZ(running power about 2KW/H)
AC220V 50HZ(运行功率约2 KW/H)
|
|
Mechanical precision
机械精度
|
±0.01mm
±0.01mm
|
|
operating system
操作系统
|
WINDOWS XP/WINDOWS 7
WINDOWS XP/WINDOWS 7
|
|
Feed quantity
喂料器数量
|
30 standard feeders can be placed
可放置标准喂料器30个
|
|
Transmission mode
传送方式
|
Automatic Output of Single Track
单段轨道自动输出
|
|
Positioning mode
定位方式
|
Visual Auto-MARK Points(8 sets of CCD Flyshot Visual Correction Cameras)
视觉自动MARK点(8组CCD飞拍视觉校正相机)
|
|
Programming mode
编程方式
|
Visual Camera Location Programming,Excel Format File Import Component
视觉相机定位编程，Excel格式文件导入元件
|
|
Plaster device
可贴装元器件
|
More than 0603 bulb resistance capacitance IC terminal and other components
0603以上灯珠电阻电容IC端子等多种元件
|
