Feature:

Key features:

1. Automated nut retrieval and riveting;

2. Solves the problem of mixed materials when handling multiple nails;

3. Left-right platform allocation supports various nuts for higher efficiency;

4. Highly intelligent and versatile, requiring no manual debugging;

5. Product replacement only requires fixture replacement and corresponding program activation.

Image:

Specification:

型号Model	CR-Tech 590A
机器尺寸Outline size	1100mm*1100mm*1700mm(L*W*H)
有效行程Effective travel	1500mm*300mm*100mm(X*Y*Z)
运动方式Mode of motion	6轴 6-Axis
定位精度Position accuracy	±0.02mm
控制系统Control system	PLC+触摸屏控制PLC+ touch screen control
供螺丝方式Feeding model	吸取式 Sunction method
锁付效率Locked efficiency	About3.0s/Piece
输入电压Power supply	220V/50Hz
输入气压Air pressure	0.4-0.7MPa
程序储存量Memory size	100group
压力Pressure	0.5T
总功率Power	2KW
