Selective Soldering Machine
Heavy Duty Selective Wave Soldering
PRODUCT DETAIL
Feature:
●Flux spraying and welding are integrated on the same platform.
● Small in size and low in energy consumption
● Transport rail load capacity: Max 50 kg
● Compatible with inverters, vehicle-mounted hot air/hot pump or heavy-duty product welding
Image:
Specification:
| 型号Model | SW-N350/M350 | SW-N500 | SW-M500 |
| 外形尺寸Dimension(L×W×H) | 1060×1240×1547 | 1400×2260×1388 | 1400×2580×1388 |
| 轨道范围(Track range) | 300*350mm | 400*500mm | 400*500mm |
| 运输高度（Transmission height） | 900±20mm | ||
| 助焊剂喷头(Flux nozzle) | 电磁泵锡炉(Electromagnetic pump solder pot) | ||
| 喷头数量(Solder pot QTY) | 单锡炉(Single solder pot) | ||
| 下预热(Bottom preheating) | 无 | 无 | 红外短波加热管 |
| 氮气加热(Nitrogen heating system) | 选配(Option) | 选配(Option) | 选配(Option) |
