Feature

Samsung pick and place machine has a great guarantee in terms of performance in use and work engineering. When it works, both in terms of efficiency and time, it has achieved the best optimization and guaranteed stability. In terms of problems, the errors and problems that occur are relatively few, almost infrequent, or can be quickly resolved once they occur. This is an advantage that other placement machines lack. It is also a prominent feature of Samsung's placement machine.

In order to increase production capacity, the PCB transmission path is optimized

Modular track
• With modular rails that can be replaced on site, better rail modules can be assembled according to the production line configuration (Shuttle ↔ Dual)
• Shortened PCB supply time by increasing the speed of the shuttle conveyor

□ Minimize the moving path of the head in order to realize the high speed of the equipment

Dual Servo Control
Realized high speed by applying linear motor to Y axis and double servo control

high speed flying head
• By identifying components during the movement process after material suction, the movement path of the Head is minimized
• 6 Spindles Head structure driven by Z axis independently

Mounting accuracy: ±40µm (0402)
• Apply high-precision Linear Scale and Rigid Mechanism
• Provide accuracy correction scheme and various automatic correction functions
