Feature:

10 Heating Zones SMT Soldering Machine Lead Free Reflow Oven For LED Soldering

1. The whole system of reflow soldering adopts a unique industrial control equipment, which reflects good stability, compatibility, reliability, and improves the anti-interference of the whole system, so that the system can run well.

2. The temperature control of reflow soldering adopts an all-round dynamic constant temperature energy storage board device to reduce the temperature difference effect in the temperature zone; at the same time, the double-sided temperature supply technology can be used to reduce and prevent the bending and deformation of the PCB board.

3. Reflow soldering has a fully automatic detection function, which can automatically detect the operation of the chain, and the ultra-low temperature sound and light alarm function.

4. Imported N2 flowmeter is used for reflow soldering. Through data acquisition and control card, accurate control of N2 concentration can be ensured.

5. Reflow soldering has a computer analysis database, which can store all the customer's data, and is equipped with different temperature curves.

Model	CR-Tech 1020
Heating System	Number of heating zones	Up 10/ bottom 10
	Number of cooling zones	2(up + bottom )
	Length of heating zones	3890mm
	Heating mode	Hot air
	Cooling Mode	Forced air cooling
	Exhaust Volume	10m³/min * 2 exhausts
Conveyor System	Max. Width of PCB	400mm
	Mesh belt width	500mm
	Transmission Direction	L→R(option: R→L)
	Transmission Net Height	900±20mm
	Transmission type	Mesh and chain
	Range of rail width	400mm
	Conveyor speed	0-2000mm/min
	Auto/manual Lubrication	Standard
	Fixed rail side	Front rail fixed(option: rear rail fixed)
	Components high	Top and bottom 25mm
Control system	Power supply	5 line 3 phase 380V 50/60HZ
	Total power	42KW
	Normal power consumption	8-10KW
	Warming time	20 mins
	Temp. setting range	From room temp. To 300℃
	Temp. control method	PID close loop control & SSR driving
	Temp. control precision	±1℃
	Temp. deviation on PCB	±2℃
	Data storage	Process Data and status storage(80GB)
	Nozzle plate	Aluminum Alloy Plate
	Abnormal Alarm	Abnormal temperature (extra-high/extra-low temperature)
	Board dropped alarm	Tower light:Yellow-warming, Green-normal, Red-abnormal
General	Dimension(L*W*H)	5800*1320*1490mm
	Weight	2100kg
	Color	Computer gray

Delivery and package:

Lead time: 10-25 working days.
